- 16 canali BNC + 8 canali IP aggiuntivi
- Tutti i 24 canali possono essere utilizzati per le telecamere IP
- Risoluzione massima 5MP
- Protocolli supportati:Onvif, Panasonic, Sony, Axis, Arecont, Pelco, Canon, Samsung
- Accesso mobile: iPhone, iPad, Android
- Supporta un HDD SATA fino a 16TB (non incluso)
- Risoluzione nativa di 3840 x 2160
- 1 DP, 2 HDMI, 1 VGA, 1 ingresso audio, 1 RJ45 (RS232), 1 USB multimediale
- Altoparlanti integrati 5Wx2
- Include cavo HDMI e cavo di alimentazione
- VESA 400x400
- Progettato per telecamere a circuito chiuso in funzionamento 24x7
Technical Specification |
||
DAHUA |
||
Model |
DHI-LM55-S400 |
|
Display |
||
Screen Size |
55" |
|
Aspect Ratio |
16:9 |
|
Resolution |
3840×2160 (UHD) |
|
Backlight |
LED |
|
Brightness/Luminance |
450cd/㎡ |
|
Contrast |
5500:1 |
|
Display Color |
1.07B(10bit) |
|
Viewing Angle(H/V) |
178°(H)/178°(V) |
|
Response time |
6ms |
|
Refresh Rate |
60Hz |
|
Signals |
||
Input |
DP 1.2a×1, HDMI 2.0×2, VGA(D-Sub)×1, USB multimedia×1, Audio×1, RJ45(RS232)×1 |
|
Output |
RJ45(RS232)×1 |
|
Speaker |
5W×2 |
|
General |
||
Power Supply |
AC100~240V (+/-10%), 50/60 Hz |
|
Consumption (Standard) |
<170W |
|
Consumption (Standby) |
≤0.5W |
|
Type |
Internal |
|
Net Weight |
25.2kg (55.6lb) |
|
Gross Weight |
35kg (77.2lb) |
|
Bezel Width |
8mm (U/L/R/B) |
|
Wall Mount |
400×400mm (15.7"×15.7") |
|
Dimension without standard (W×H×D) |
1227.2×699.6×65.0mm (48.3"×27.5"×2.6") |
|
Package(W×H×D) |
1410×875×255mm (55.5"×34.4"×10.0") |
|
Work Environment |
Temperature |
0℃~40℃ (32°F~104°F) |
Humidity |
10%~85% |
|
Accessory |
||
Standard |
HDMI cable, power cable, hanging bracket, remote control |
|
Optional |
Pedestal |
|
Certifications |
||
Certifications |
CE/FCC |
