Board and monitor | Allow only 1 monitor
Connection for 4 wires
Mobile App with P2P | Internal relays on monitor
Surface mounting | IP65
DS-KH6320-WTDE1 |
|
| Brand | Hikvision |
| Model | DS-KH6320-WTDE1 |
| Operating system | Linux |
| Screen type | 7" color touch-screen TFT |
| Screen resolution | 1024 x 600 |
| Inputs | 2 x configurable alarm inputs, 1 x RS485, 1 x 4 wires |
| Outputs | 2 x relay outputs, 1 x 4 wires |
| Audio | Two-way audio with integrated microphone and loudspeaker Noise reduction and echo cancellation |
| Memory | MicroSD card slot (up to 128 GB) |
| Connection | 4 wires / Ethernet 10/100 BaseT / RTSP / SIP Protocol 2.0 / WiFi 802.11 b/g/n (only for connection to app via P2P) |
| Remote access | Software iVMS-4200 Hik-Connect mobile app |
| Power | DC 12 V / 500 mA máx. / IEEE802.3af PoE |
| Temp. operation | -10º C ~ +55º C |
| Dimensions | 140 (H) x 200 (W) x 15 (D) mm |
| Weight | 340 g |
| Slave monitors | It is not possible to use the Android DS-KH9310 and DS-KH9510 monitors as slaves |
DS-KB2421T-IM |
|
| Brand | Hikvision |
| Model | DS-KB2421T-IM |
| Operating system | Embedded analog operating system |
| Image sensor | 1/2.7" 2 Mpx CMOS IR |
| Viewing angle | H: 66º, V: 37º |
| Audio | Bidirectional audio with microphone and speaker |
| Keypad | Mechanical call button |
| Outputs | 1 x relay output |
| Inputs | 1 x 4 wires |
| Communication | 4 wires |
| Power | DC 12 V / 420 mA máx. (via monitor by 4 wires) |
| Degree of protection | Suitable for exterior IP65 |
| Material | Aluminium alloy |
| Temp. operation | -10º C ~ +55º C |
| Dimensions | 135 (H) x 50 (W) x 42 (D) mm |
| Weight | 340 g |
Board and monitor | Allows up to 16 monitors more
MF Reader | PoE
Mobile App P2P (activation from wizard monitor)
Surface mounting | IP65
Board and monitor | Allows up to 8 monitors more
Easy-to-configure firmware without network
Mobile App with P2P | Stainless Steel
Surface mounting | IP65, IK08
Board and monitor | Allows up to 16 monitors more
MF Reader | PoE
Mobile App P2P (activation from wizard monitor)
Surface mounting | IP65
Board and monitor | Allows up to 16 monitors more
Facial, MF card and QR | PoE
Mobile App with P2P | Internal relays on monitor
Surface mounting | IP65
Board and monitor | Allows up to 16 monitors more
Easy-to-configure firmware without network
Mobile App with P2P | Internal relays on monitor
Surface mounting | IP65
Board and monitor | Allows up to 16 monitors more
MF Reader | PoE
Mobile App P2P (activation from wizard monitor)
Surface mounting | IP65
Board and monitor | Allows up to 2 monitors more
Connection for 2 wires
Plug & Play installation
Surface mounting | IP65, IK07
Board and monitor | Allows up to 16 monitors more
MF Reader | PoE
Mobile App P2P (badge activation)
Surface mounting | IP65
