| Brand | Ajax |
| Frequency | 868 MHz Jeweller |
| Transmission distance | ≤ 2000 m in open space |
| Anti-inhibition detection | Available |
| Wired inputs | Up to 18 (alarm and tamper) |
| Alarm inputs | NO/NC or end-of-line resistance EOLR (NO/NC) / Impulse or bidirectional |
| End-of-line resistor EOL | From 1 kΩ to 7.5 kΩ |
| Tamper input | NC: Normally Closed |
| Tamper-resistant opening | Front and back |
| Power supply output | Two outputs 12 V / 1 A (in total) for wired sensors |
| Compatibility | Compatible with Ajax Hub, Hub Plus, Hub 2, Hub 2 Plus and ReX |
| Power | AC 110~250 V, 50/60 Hz |
| Backup battery | Battery 12 V / 4 or 7 Ah (not included) |
| Temp. operation | -10 ºC ~ 40 ºC |
| Dimensions of the backup battery | 150 (H) x 64 (W) x 94 (D) mm |
| Dimensions | 196 (H) x 238 (W) x 100 (D) mm |
Ajax Alarm Panel
Grade 2 Certificate
Ethernet and GSM / GPRS communication
Wireless 868 MHz
Supports 100 wireless accessories
Integration of up to 25 IP cameras or DVRs
Compatible with PIR CAM detector available soon
Smartphone and web app
White color
Ajax Alarm Panel
Grade 2 Certificate
Ethernet and GSM / GPRS communication
Wireless 868 MHz
Supports 100 wireless accessories
Integration of up to 25 IP cameras or DVRs
Compatible with PIR CAM detector available soon
Smartphone and web app
White color
Composed by:
AJAX HUB Control Panel
PIR Detector MOTIONPROTECT-W
Magnetic Contact DOORPROTECT-W
Remote control SPACECONTROL-W
Camera IP WIFI 2 Mpx SF-IPCV220WH-2W
